SCHROEDER MHSUV 3200/3.0 metal band saw

PDF
SCHROEDER MHSUV 3200/3.0 metal band saw - Machineryline
SCHROEDER MHSUV 3200/3.0 metal band saw | Image 1 - Machineryline
SCHROEDER MHSUV 3200/3.0 metal band saw | Image 2 - Machineryline
SCHROEDER MHSUV 3200/3.0 metal band saw | Image 3 - Machineryline
SCHROEDER MHSUV 3200/3.0 metal band saw | Image 4 - Machineryline
SCHROEDER MHSUV 3200/3.0 metal band saw | Image 5 - Machineryline
SCHROEDER MHSUV 3200/3.0 metal band saw | Image 6 - Machineryline
Interested in the ad?
1/6
PDF
Price:
on request
Ask for price
Contact the seller
Year of manufacture: 2002
Net weight: 7,738 lb
Location: Germany Ahaus6623 km to "United States/Columbus"
Seller stock ID: 1008-9325413
Placed on: Jun 15, 2025
Description
Overall dimensions: 13.35 ft × 6.79 ft × 4.59 ft
Condition
Condition: used

More details — SCHROEDER MHSUV 3200/3.0 metal band saw

English
sheet width 3230 mm
plate thickness 3.00 mm
thickness at "Niro-steel" 1.75 mm
no. of strokes 34 Hub/min
cutting angle 1.60 Grad
table height 820 mm
distance between columns 3540 mm
Control POS 100
air pressure 6.0 bar
engine output 6.8 kW
weight of the machine ca. 3510 kg
range L-W-H 4070 x 2070 x 1400 mm
** Current new price including accessories approx. 70.000 Euro
** From a maintenance workshop
** Very good condition (!!)
** Special price upon request

Features:
- Robust / motorized swing cut guillotine shear
- Shatter-proof, torsion-free welded steel construction
- Compact and clearly arranged machine design
- NC electro-motorized backgauge
* With SCHRÖDER NC POS 100 control unit
* Adjustable from the front right
* With target/actual value input
* Continuous adjustment across the entire travel range
* Coarse adjustment via pushbuttons
* Limit value protection with limit switches
- "Duo-Cut" drive with two dynamic, powerful gear motors
- Support table with recessed grips
- Hold-down bar with hard rubber strip
- All-steel blade
- 1x side stop with T-slot and digital mm scale
- 2x extended sheet support arms
- Selector switch for single and Continuous stroke
- 1x freely movable foot switch
- Rear safety device (side guards)
- Original operating instructions

** Optional accessories included:
- Pneumatically controlled sheet support device for thin sheet blanks
* Sheet removal / sheet slide to the front (operator side)
The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Blechbreite 3230 mm
Hubzahl 34 Hub/min
Schnittwinkel 1.60 Grad
Steuerung POS 100
Luftdruck 6.0 bar
Motorleistung 6.8 kW
Maschinengewicht ca. 3510 kg
Abmessung L-B-H 4070 x 2070 x 1400 mm
