Used Blow Molding Machine SMI SR10HP year 2015
Firstly, the SMI SR10HP, produced in 2015, emerges as an advanced solution for PET container production. This analysis aims to detail its technical specifications and operational features. It significantly highlights the machine’s efficiency and productive capacity in industrial environments.
Productive Capacity and Versatility of the Blow Molding Machine SR10HP
Importantly, the machine achieves a remarkable speed of 22,000 BPH, showcasing its high capacity. It adeptly processes a variety of container sizes, including 0.20 L, 0.33 L, and 0.6 L, thereby offering considerable flexibility in production lines.
Configuration and Components
Moreover, it boasts ten cavities for simultaneous preform processing, which optimizes production time. Integrated systems, such as a loader, tipper, and unscrambler, automate preform handling. Consequently, these systems minimize manual intervention and significantly boost operational efficiency.
Technology and Innovation of the Blow Molding Machine SR10HP
Additionally, a compressor and chiller are crucial for controlling temperature and air pressure, ensuring the quality of PET containers. Furthermore, an air recovery system innovatively reduces energy consumption, highlighting a strong commitment to sustainability.
Standards and Compatibility
Equally important, the machine operates with 1881 neck type preforms, a widely accepted standard, ensuring compatibility with various bottling lines. Its rotary design facilitates high-speed production while maintaining high-quality standards, thereby ensuring reliability.
Operational Status and Safety
Currently, the Blow Molding Machine SR10HP is in operation and meets strict safety standards, effectively protecting operators. Provided manuals support efficient maintenance and optimal machinery use, enhancing operational longevity.
Electrical Data
On the electrical front, specifications require 380V, with a consumption of 300kW and an intake of 494A. This detail underscores the machine’s commendable energy efficiency.
It is important to note that during the refurbihìshment of this machine, these maintenence activities were made:
Maintenance of oven pickup, holder & oven lamp unit
Maintenance of inlet & outlet gripper & gripper unit
Maintenance of all the bottom mould, linear bearing and CAM
Maintenance of 4 blowing station
Maintenance of Main carousel motor, gear box with supporting unit
Done assembly work in gear box unit
Done the service for removed mould stations and fixed
Assembled Inlet and outlet gripper CAM
Dismantled elevator unit
Installed new conveyor belt and sub assembly of elevator
Installed new air filter for high pressure unit
Maintenance of remaining blowstations
Done the service for blowing stations
Oven exhaust fan removed and cleaned
Installed the blowing stations and completely Maintenance of two blowing stations
Installment of the valves and solenoid coils
Done the complete service for inlet gripper unit
Maintenance of water distributor and make service and install it
Service air distributor and install it
Service outlet gripper unit
Installment out let gripper cam unit
Installment inlet and out let grippers
Open and clean oven cooling system
Open and check electrical distributor
Changement of the two mould stretch rod dive belt
Installment of the inlet and outlet gripper unit
Installment electrical distributor
Change damage pipe ni water distributor
Change stretch rod belt
Installment complete blowing station
Installment preform pick up and guide
Installment and clean all oven lamp
Installment blowing wheel drive unit
Installment 8 pcs bottom cam bearing
Elevator belt adjustment
Stretch rod fix Bottom cam fix
Installment 2pcs bottom cam bearing
Check all bottom cam
Preform pick upper and guide installment
Trial run
Cleanining of coil and valves are not function
Cleanining of blowing valve in mould no:2
Making trail run in 200 ml
Making trail running
Mould no:10 not working stretch rod
Mould no :2 blowing valve not working
Order spare part to replace the damage part
Conclusion
In conclusion, the 2015 SMI SR10HP machine stands out for its productive capacity, energy efficiency, and technical sophistication. With a strong focus on sustainability, it represents an ideal choice for industries seeking reliable, high-quality solutions for PET container production.
Speed: 22000 BPH
Containers: PET
Formats: 0.20 L, 0.33 L, 0.6 L
Electrical data: V: 380Vkw: 300kwA: 494A
Safety features: Yes
Manuals: Yes
No. of cavities: 10
Elevator: Yes
Preforms tipper: Yes
Unscrambler: Yes
Compressor: Yes
Chiller: Yes
Preform neck type: 29/25
Air Recovery System: Yes
Type: Rotary
brand: SMI
