Gildemeister SPEED 32/10 linear metal lathe
Kaiserslautern
If you decide to buy equipment at a low price, make sure that you communicate with the real seller. Find out as much information about the owner of the equipment as possible. One way of cheating is to represent yourself as a real company. In case of suspicion, inform us about this for additional control, through the feedback form.
Before you decide to make a purchase, carefully review several sales offers to understand the average cost of your chosen equipment. If the price of the offer you like is much lower than similar offers, think about it. A significant price difference may indicate hidden defects or an attempt by the seller to commit fraudulent acts.
Do not buy products which price is too different from the average price for similar equipment.
Do not give consent to dubious pledges and prepaid goods. In case of doubt, do not be afraid to clarify details, ask for additional photographs and documents for equipment, check the authenticity of documents, ask questions.
The most common type of fraud. Unfair sellers may request a certain amount of advance payment to “book” your right to purchase equipment. Thus, fraudsters can collect a large amount and disappear, no longer get in touch.
- Transfer of prepayment to the card
- Do not make an advance payment without paperwork confirming the process of transferring money, if during the communication the seller is in doubt.
- Transfer to the “Trustee” account
- Such a request should be alarming, most likely you are communicating with a fraudster.
- Transfer to a company account with a similar name
- Be careful, fraudsters may disguise themselves as well-known companies, making minor changes to the name. Do not transfer funds if the company name is in doubt.
- Substitution of own details in the invoice of a real company
- Before making a transfer, make sure that the specified details are correct, and whether they relate to the specified company.
Seller's contacts
+49 162 40...
Show
+49 162 4027581
Germany, Kaiserslautern
Germany, Bühl-Weitenung
Germany, Peiting
Germany, Cologne
CNC: Fanuc 310iS
Panel type: SlimLine
Screen: 15" TFT Color
Controlled spindles (including C axes): 2
Controlled axes: 8
Channels: 3
Bar capacity: 33 mm (36 mm max)
Draw tube inner diameter: 46 mm
Maximum speed: 8000 rpm
Nominal torque (S1): 24 Nm
Nominal power (S1): 5.5 kW
Draw tube inner diameter: 38 mm
Maximum speed: 8000 rpm
Nominal torque (S1): 9.4 Nm
Nominal power (S1): 3.7 kW
Axis X1Travel: 50 mmMaximum speed: 40 m/minMaximum acceleration: 10 m/s²Nominal thrust (S1): 1200 NAxis Y1Travel: 350 mmMaximum speed: 30 m/minMaximum acceleration: 5 m/s²Nominal thrust (S1): 5000 NAxis Z1Travel: 320 mmMaximum speed: 40 m/minMaximum acceleration: 5 m/s²Nominal thrust (S1): 2500 NAxis X2Travel: 310 mmMaximum speed: 40 m/minMaximum acceleration: 5 m/s²Nominal thrust (S1): 2500 NAxis Z2Travel: 320 mmMaximum speed: 40 m/minMaximum acceleration: 5 m/s²Nominal thrust (S1): 2500 NAxis X3Travel: 80 mmMaximum speed: 40 m/minMaximum acceleration: 5 m/s²Nominal thrust (S1): 1200 NAxis Y3Travel: 60 mm (±30 mm)Maximum speed: 18 m/minMaximum acceleration: 5 m/s²Nominal thrust (S1): 5000 NAxis Z3Travel: 150 mmMaximum speed: 40 m/minMaximum acceleration: 5 m/s²Nominal thrust (S1): 2500 NTurretTotal stations: 16Fixed external tools: 8Tool shank size: 16×16 mmDriven tool stations: 16Collet type: ESX/ER 20Maximum driven speed: 5000 rpmNominal torque (S1): 4.8 NmNominal power (S1): 1.5 kWToolsToolholder Slide 1Total stations: 10Fixed external tools: 6Tool shank size: 16×16 mmDriven tools: 4Collet type: ESX/ER 20Maximum driven speed (GEO 7–9): 5000 rpmNominal torque (S1): 2.19 NmNominal power (S1): 0.55 kWSecondary driven speed (GEO 8–10): 3333 rpmNominal torque (S1): 3.28 NmNominal power (S1): 0.55 kWBack Working SlideTotal stations: 4 + 2Internal fixed tools: 3Toolholder diameter: 25 mmExternal fixed tools: 1Driven stations: 2Collet type: ESX/ER 16Maximum driven speed: 6000 rpmNominal torque (S1): 1.75 NmNominal power (S1): 0.55 kWMediaLubrication SystemTank capacity: 2.9 LOperating pressure: 30 barStop time: 7 minutesOperating cycle time: 30 secondsLubricant type: Castrol Magna BD 68Pneumatic SystemMinimum operating pressure: 5 barMaximum operating pressure: 6 barConsumption: 60 NL/min
Travel: 50 mm
Maximum speed: 40 m/min
Maximum acceleration: 10 m/s²
Nominal thrust (S1): 1200 N
Travel: 350 mm
Maximum speed: 30 m/min
Maximum acceleration: 5 m/s²
Nominal thrust (S1): 5000 N
Travel: 320 mm
Maximum speed: 40 m/min
Maximum acceleration: 5 m/s²
Nominal thrust (S1): 2500 N
Travel: 310 mm
Maximum speed: 40 m/min
Maximum acceleration: 5 m/s²
Nominal thrust (S1): 2500 N
Travel: 320 mm
Maximum speed: 40 m/min
Maximum acceleration: 5 m/s²
Nominal thrust (S1): 2500 N
Travel: 80 mm
Maximum speed: 40 m/min
Maximum acceleration: 5 m/s²
Nominal thrust (S1): 1200 N
Travel: 60 mm (±30 mm)
Maximum speed: 18 m/min
Maximum acceleration: 5 m/s²
Nominal thrust (S1): 5000 N
Travel: 150 mm
Maximum speed: 40 m/min
Maximum acceleration: 5 m/s²
Nominal thrust (S1): 2500 N
Total stations: 16
Fixed external tools: 8
Tool shank size: 16×16 mm
Driven tool stations: 16
Collet type: ESX/ER 20
Maximum driven speed: 5000 rpm
Nominal torque (S1): 4.8 Nm
Nominal power (S1): 1.5 kW
Total stations: 10
Fixed external tools: 6
Tool shank size: 16×16 mm
Driven tools: 4
Collet type: ESX/ER 20
Maximum driven speed (GEO 7–9): 5000 rpm
Nominal torque (S1): 2.19 Nm
Nominal power (S1): 0.55 kW
Secondary driven speed (GEO 8–10): 3333 rpm
Nominal torque (S1): 3.28 Nm
Nominal power (S1): 0.55 kW
Total stations: 4 + 2
Internal fixed tools: 3
Toolholder diameter: 25 mm
External fixed tools: 1
Driven stations: 2
Collet type: ESX/ER 16
Maximum driven speed: 6000 rpm
Nominal torque (S1): 1.75 Nm
Nominal power (S1): 0.55 kW
Tank capacity: 2.9 L
Operating pressure: 30 bar
Stop time: 7 minutes
Operating cycle time: 30 seconds
Lubricant type: Castrol Magna BD 68
Minimum operating pressure: 5 bar
Maximum operating pressure: 6 bar
Consumption: 60 NL/min
application type: Turning
Location: Italy
machine type: Horizontal Turning Machine
control unit brand: FANUC
Control Brand: FANUC
Control Model: Fanuc 310
